Champion 3 Row Aluminum Radiator Combo for 1969 -1970 Chevy Impala, Bel Air CC345FANRLY

Champion Cooling System radiators feature either a two, three or four row core configuration of 5/8" or 3/4” tubes for maximum cooling power, uniform heat transfer and increased air flow and corrosion-resistant lightweight aluminum construction tig-welded (no epoxy) for superior strength. Manufactured at an ISO-Certified Facility to the highest quality standards and precision workmanship in the industry. All are backed by a Limited Lifetime Warranty.
Not Available
Pricing: $389.99


Champion 3 Row Aluminum Radiator Combo for 1969 to 1970 Chevrolet Impala, Bel Air, Caprice, Biscayne, Kingswood, Brookwood
with 250ci, 350ci, 400ci and 454ci Engines
Includes radiator, one 16" electric fan and one electric fan relay kit


Core Height: 15 1/2"
Core Width: 23 1/2"
Overall Height: 22"
Overall Width: 28 1/4"
Inlet Diameter: 1 1/2"
Outlet Diameter: 1 3/4"
Upper Hose Fitting: Driver
Lower Hose Fitting: Passenger
Trans Cooler: Yes
Mounting Type: Bracket
Rows: Three
Core Thickness: 2 1/4"
Tank Thickness: 2 1/2"
Type: Down Flow
Core: Three Rows 5/8"



Shipping Information

  • Item Requires Shipping
  • Free Shipping (Lower 48)
